| System Specifications |
| Networking |
| Ethernet |
10/100 Base Ethernet |
| Modem |
PPP(Dial-up, direct connection) |
| Protocol |
TCP/IP, PPP, HTTP, DHCP, SMTP, FTP,
Telnet, NTP, UDP and DNS |
| Video |
| Compression |
Motion-JPEG |
| Inputs |
4 BNC composite with 75 £[
termination |
| Resolution |
NTSC |
Up to 30fps at 176x120 |
| Up to 30fps at 352x240 |
| Up to 10fps at 704x480 |
| PAL |
Up to 25fps at 176x144 |
| Up to 25fps at 352x288 |
| Up to 10fps at 704x576 |
| Features |
Adjustable image size and quality |
| NTSC/PAL auto detection |
| Quad screen function |
| Time stamp and text overlap |
| System
Management |
| Configuration |
Controlled by web browser or FTP
applet |
| Security |
Administrator and user group |
| Password authentication |
| Demo account with limited features |
| Upgradeable via FTP remotely |
| Alarm
Features |
| Motion Detection |
Programmable sensitivity and
percentage |
| Pre/Post Alarm |
3 color images snapshot per camera |
| Automatic Retrieval |
Images sent via FTP or email |
| Interface |
| General
I/O |
4 sensor inputs(max. 12V DC 50 mA) |
| 2 relay outputs(max. 24V DC 1A, 125V
AC 0.5A) |
| RS232/RS-485 |
Modem connection or PTZ control(max.
115.2kbps) |
| LED Indicator |
Power/System Status/Network |
| PTZ Camera
Control |
| Camera Model |
Auto detection |
| Camera
and Protocol |
Sony VISCA |
| Canon VC-C1, VC-C3 |
| Pelco D |
| DynaColor DynaDome |
| Driver Support |
Clear-data command |
| Physical |
| External
Power Adapter |
Input: 100-240V AC , 0.8A |
| Output: +12V DC, 2A |
| Dimensions |
194mm (W) x 194mm (D) x 44.5 (H) |
| Weight |
Approx. 1.1Kg |
| Client Recording Software |
| Display |
| Resolution |
NTSC |
172x112, 352x240, 704x480 |
| PAL |
172x144, 352x288, 704x576 |
| Quality |
Excellent/Detailed/Good/Standard/Medium |
| Channel Layout |
1/4 |
| Recording |
| Mode |
Scheduler/Even driven/Manual control |
| Frame Rate |
1 - 30 fps |
| Playback |
| Scheme |
Date/Time interval/Event trigger |
| Control |
Play/Stop/Fast Foreard/Slow
Forward/Step Forward/Pause/Jog Shuttle/Zoom In/Zoom out |
| Speed |
1/16 - 16x |
| Advanced
Feature |
| Momitor
Detection |
3 detection windows for each channel |
| Adjustable sensitivity and detection
size |
| Security |
Automatic sending images via email
or FTP while event triggered |
| Alarm sound |
| Remote
Control |
PTZ camera control |
| Telnet control for DI/DO |
| Exporting Format |
AVI/Bitmap/Print-out |
| Monitoring System Minimum Requirement |
| Protocol |
Standard Internet TCP/IP suite |
| Operating System |
Windows95/98/ME/2000/XP/NT, Linux,
Unix, and Mac |
| Browser |
Internet Explorer 4.x or Netscape
Navigator 4.x |
| Minimum System Requirement for Video Recording
Software |
| Operating System |
Windows 98/ME |
| CPU |
Intel Pentium III 750Mhz or above |
| System Memory |
128MB |
| Display Adapter |
nVidia series based card with 32MB
memory |
| Hard Disk Space |
40GB(for video storage) |
